Delivery time : 2 to 3 weeks

EYEPIECES
Pair of DIN HWF plan 10x/22 mm eyepieces

HEADS
• Trinocular 45° inclined tubes with extended low and high positions for eyepieces
• One diopter adjustment on left eyepiece
• Interpupillary distance of 54 to 75 mm
• Trinocular head with 100-0 % and 80-20 % positions

NOSEPIECES
Revolving quintuple nosepiece on ball-bearings

OBJECTIVES FOR BRIGHTFIELD
(models OX.2003-PL and OX.2053-PL)

• Infinity color corrected long working distance plan 10x/0.25, 20x/0.40, 40x/0.60 IOS objectives
• An optional 60x/0.70 IOS objective is also available

OBJECTIVES FOR PHASE CONTRAST
(models OX.2003-PLPH and OX.2053-PLPH)

Infinity color corrected long working distance plan phase 10x/0.25, 20x/0.40, 40x/0.60 IOS objectives

(Photo: OX.9190 Slider with 4x/10x and 20x/40x phase contrast annuli)

OBJECTIVES FOR BRIGHTFIELD AND FLUORESCENCE MICROSCOPY
(models OX.2253-PLF and OX.2453-PLF)

• Infinity color corrected long working distance plan Fluarex 10x/0.30, 20x/0.45, 40x/0.65 IOS objectives
• An optional plan Fluarex 60x/0.75 IOS objective is also available

OBJECTIVES FOR PHASE CONTRAST AND FLUORESCENCE MICROSCOPY
(models OX.2253-PLPHF and OX.2453-PLPHF)

Infinity color corrected long working distance plan fluarex 10x/0.30 and plan phase fluarex 20x/0.45 and S40x/0.65 IOS objectives.

All objectives corrected for 1.2 mm thickness.
All optics are anti-fungus treated and anti-reflection coated for maximum light throughput

STAGE
Stage 250 x 230 mm equipped with a coaxial mechanical 120 x 78 mm X-Y stage, delivered with:

• metallic insert for Ø 35 mm cell culture dish dishes
• 76 x 26 mm slide holder
• glass insert with hole

optional universal cell culture dish holder
(Photo: OX.9599 Universal cell structure dish holder)

CONDENSER
• N.A. 0.30 condenser with iris diaphragm. Working distance 72 mm
• The models for the phase contrast OX.2003-PLPH, OX.2053- PLPH, OX.2253-PLPHF and OX.2453-PLPHF are delivered with a slider with 4x/10x and 20x/40x pre-centered phase rings

FOCUSING ADJUSTMENT
Coaxial 25 mm coarse and fine adjustments, 2 μm precision and with friction adjustment

ILLUMINATION
• Transmitted 5 W LED Intensity adjustable with internal 100-240 V power supply. Fuse holder 3.15 A / 250 V.
• The fluorescence models are equipped with a reflected 100 W HBO mercury vapor light source with external 100-240 V power supply, fuse holder 3.15 A / 250 V, UV protection shield

FILTERS FOR PHASE CONTRAST MODELS
Interference filter 550 nm green and blue filter, 45 mm diameter

STANDARD FLUORESCENCE FILTERS
(for fluorescence models)

The fluorescence models OX.2253-PLF and OX.2453-PLF are standard supplied with two filter sets for excitation:
- in the blue spectrum, OX.9745, EX465-495 (BP) DM505 (LP) EM515-558 (BP)
- in the green spectrum, OX.9746, EX520-600 (BP) DM600 (LP) EM605-665 (BP)

The fluorescence models OX.2253-PLF and OX.2453-PLPHF equipped with a 4 positions filter rail equipped with three standard filter sets for excitation:
- in the blue spectrum, OX.9745, EX465-495 (BP) DM505 (LP) EM515-558 (BP)
- in the green spectrum, OX.9746, EX520-600 (BP) DM600(LP) EM605-665 (BP)
- in the UV spectrum, OX.9747, EX361-381 (BP) D415 (LP) EM435-495 (BP)

STANDARD GENERAL PURPOSE FLUORESCENCE FILTERS SETS

OX.9745 Blue excitation 465-495 nm

FITC EX465-495 (BP) DM505 (LP) EM515-558 (BP)
Also suitable for: Acridine Orange + DNA, Alexa Fluor 488™, Atto 488, Azami Green, BODIPY FL/pH7.2, Calcein, Calcium Green™-1, Cy2™, DiO, DyLight 488, EGFP, Emerald GFP, FAM, FITC, Fluo-4, GFP LysoTracker Green/pH 5.2, MitoTracker Green FM/MeOH, mWasabi, Oregon Green™ 488, SYBR® Green I, SYTO 9/DNA, ZsGreen


OX.9746 Green excitation 520-600 nm

Texas Red / mCherry / Alexa Fluor 594 EX520-600 (BP) DM600 (LP) EM605-665 (BP)
Also suitable for: Alexa Fluor 568™, Alexa Fluor 594™, CAL Fluor® Red 610, Cy3.5™, DyLight 594, FusionRed, Killer Red, mCherry, MitoTracker Red/MeOH, mKate2, mRFP1, ReAsH-CCPGCC, Rhodamine Red™-X, ROX, Sulforhodamine 101, Texas Red®, Texas Red®-X, X-rhod-1/Ca2+


OX.9747 UV excitation 361-381 nm

DAPI / Hoechst / Alexa Fluor 350 EX361-381 (BP) D415 (LP) EM435-495 (BP)
Also suitable for: Alexa Fluor 350™, Biosearch Blue, Coumarin, DAPI, DyLight 350, Hoechst 33258, LysoTracker Blue/MeOH

OX.9748 Violet excitation 361-389 nm

UV / DAPI Longpass, Calcofluor White EX 361-389 (BP) DM 415 (LP) EM 435 (LP)

 PACKAGE CONTENT
• Supplied with power cord, dust cover and user manual
• Phase contrast models are supplied with green filter and alignment telescope
• Microscope supplied in a transport case
